HLMJX-16W
Hualong
Here's the HLMJX-16W Multi Head Continuous Granite Processing machine by Hualong Machinery. This advanced Stone Polishing Machine is designed to revolutionize the stone industry with its intelligent control system and user-friendly interface. With the ability to adjust the grinding head working width and pressure, it ensures precise and tailored polishing for different stone materials, making it the perfect choice for Automatic Stone Line Polishing. Equipped with a sensor at the entrance, this machine scans stone slab shapes, enabling precise and consistent stone processing for high-quality results. The central automatic lubrication system ensures that all machine components and bearings are well-lubricated, enhancing reliability and longevity. Additionally, the self-cleaning and stone chip removal system maintains a clean and safe production environment, reducing impurities and contamination during the manufacturing process. Experience flexibility, precision, and efficiency with the HLMJX-16W Multi Head Continuous Granite Processing machine. Trust Hualong Machinery for all your stone machinery needs.
TECHNICAL DATA | ||||
Model No. | HLMJX-8 | HLMJX-12 | HLMJX-16 | HLMJX-20 / 24 |
Quantity of grinding head (pc) | 8 | 12 | 16 | 20 / 24 |
Power of spindle motor (kw) | 7.5 | 7.5 | 7.5 | 7.5 |
Gross power (kw) | 78 | 108 | 135 | 168 / 198 |
Useful working width (mm) | 300-1250 | 300-1250 | 300-1250 | 300-1250 |
Processable thickness (mm) | 10-60 | 10-60 | 10-60 | 10-60 |
Speed of belt advance (m/min) | 0-3.8 | 0-3.8 | 0-3.8 | 0-3.8 |
Water consumption (m3/min) | 10 | 16 | 20 | 23 / 25 |
Gross weight (kg) | 9000 | 12000 | 15000 | 18000 / 21000 |
Demension (L x W x H - cm) | 556x222x226 | 676x222x226 | 796x222x226 | 916(1036)x222x226 |
Main Features of the Multi Head Continuous Granite Processing (HLMJX-16W) Stone Polishing Machine:
1. PLC electrical system and LCD screen menu offer intelligent control for easy operation and precise adjustments.
2. Processing width and working pressure of grinding heads can be freely adjusted, allowing for versatile and customizable stone polishing.
3. Sensor at the entrance scans the shape of the slabs in sequence and transmits the signal to the controlling unit, ensuring precise and efficient working.
4. Central automatic lubrication system ensures all moving parts and bearings are well lubricated, resulting in a longer lifespan and optimal performance.
5. Conveyor self-cleaning and stone chip removing system eliminates debris and ensures a clean working environment, enhancing productivity and efficiency.
Product Advantages:
1. Intelligent Control System: The HLMJX-16W Multi Head Continuous Granite Processing machine, designed by Hualong Machinery, is equipped with an advanced PLC electrical system and an LCD screen menu, providing intelligent control for ease of operation and enhanced efficiency.
2. Flexible Work Parameters: The HLMJX-16W allows for the flexible adjustment of grinding head working width and pressure, catering to the specific processing needs of various types of stone, enhancing machine versatility.
3. Precision Work: This innovative machine incorporates a sensor at the entrance that scans the shape of stone slabs in sequence, transmitting signals to the control unit for precise and consistent stone processing.
4. Automatic Lubrication System: The HLMJX-16W features a central automatic lubrication system that ensures all moving parts and bearings are well-lubricated, prolonging the machine's lifespan and reducing maintenance requirements.
5. Self-Cleaning and Stone Chip Removal System: With its self-cleaning mechanism and stone chip removal system, the HLMJX-16W maintains a clean working area, reducing the manual cleaning effort and enhancing overall efficiency.
These advantages make the HLMJX-16W Multi Head Continuous Granite Processing machine from Hualong Machinery an ideal choice for stone polishing, offering intelligent control, flexibility, precision, automatic lubrication, and a self-cleaning system.
1. Multi Head Continuous Granite Processing: This stone polishing machine, specifically designed for continuous honing and polishing of marble slabs, is also highly suitable for processing granite. With its multi-head feature, it can efficiently and effectively polish granite, ensuring a high-quality polished finish.
2. Stone Polishing Machine: Our HLMJX-16W model is an automatic stone line polishing machine that offers exceptional polishing results for various stone types. It can be used for polishing quartz, granite, and other natural or artificial stones, making it a versatile and reliable choice for stone processing.
3. Automatic Stone Line Polishing Machine: With its high degree of automation, our stone polishing machine is ideal for mass production. It is specifically designed to meet the demands for polished stone products in bulk, making it a valuable asset for stone processing companies looking to increase their production efficiency.
4. Marble Polishing Line Machine: The HLMJX-16W model from Hualong Machinery is particularly suitable for marble polishing. Its continuous honing and polishing capabilities ensure high production efficiency, allowing for the processing of marble slabs with a high-quality polished finish.
5. Granite Line Polishing Machine for Granite Marble: Our stone polishing machine is specifically designed to process both granite and marble. Its multi-head feature and ability to match different types of grinding heads make it a versatile choice for achieving exceptional polishing results on both granite and marble surfaces.
