HLQY-2500
Hualong Machinery
Here's the Block Cutting Machine 2500 by Hualong Machinery, a revolutionary solution for the stone industry. This machine is equipped with 6 big strong pillars, acting as sliding guides for the spindle, ensuring smooth and precise cutting. Covered by fabric, it effectively prevents pollution and maintains the quality of the finished products. The Hiwin Linear Guide, renowned for its top quality and performance, is used on the crossbeam and carling, guaranteeing exceptional results. The Circle Blade, with the capacity to hold up to 18 pieces, enables efficient production of thin slabs. The electronic control system, powered by Siemens, ensures stability and high automation performance. Designed for cutting granite and marble blocks, this machine is the epitome of excellence in the stone machinery industry. Trust Hualong Machinery for all your cutting needs.
TECHNICAL DATA | ||||
Model | HLQY-1600 | HLQY-2500 | HLQY-3000 | |
Max. blade diameter | mm | Φ1600 | Φ2500 | Φ3000 |
Cross beam type | A / B | A / B | ||
Cross beam length | mm | 6000 | 7600 / 8300 | 8300 / 9300 |
Cutting length | mm | 3500 | 3500 | 3500 |
Cutting wideth | mm | 2000 | 2000 | 2000 |
Lifting stroke | mm | 800 | 1350 | 1350 |
Power of main motor | kw | 55 (4P) | 55 (4P) | 55 (6P) |
Power of pump motor | kw | 4 | 4 | 4 |
Power of stroke motor | kw | 2.2 | 2.2 | 2.2 |
Power of vertical motor | kw | 1.1 | 1.1 | 1.1 |
Gross power | kw | 62.3 | 62.3 | 62.3 |
Gross weight | 10000 | 13000/14000 | 14000/15500 | |
Dimensiona(L x W x H) | 650x500x400 | 780x500x450 | 780x500x450 | |
Main Features of the Hualong Machinery Block Stone Machine (Model 2500):
1. Siemens Smart PLC Control System: Ensures high automation performance and ease of use, enhancing productivity and efficiency.
2. 4 Pillar Spindle Sliding Structure: Provides stability and ensures steady machine structure, resulting in stable lifting operations.
3. Synchronized Two-Slider Frame Structure: Driven by a high-stiffness screw, this structure offers exceptional stability and stiffness for precise cutting operations.
4. X and Y Axes Sliding System: Equipped with linear guides and racks, the sliding system operates smoothly and efficiently, aided by oil bath lubrication.
5. High Production Capability: The combination of advanced control system, stable structure, and efficient sliding system enables the machine to achieve high production rates.
These main features make the Hualong Machinery Block Stone Machine (Model 2500) an ideal choice for cutting blocks of various materials, including granite and marble. With its Siemens Smart PLC Control System, stable structure, and efficient sliding system, this machine ensures high automation performance, stability, and smooth operation, resulting in increased productivity and quality output.
1. High Automation: The integration of Siemens smart PLC control system ensures a high level of automation, making the Hualong Machinery 2500 Block Cutting Machine user-friendly and efficient.
2. Structural Stability: With a four-pillar design for spindle sliding and a synchronized, screw-driven two-slider frame structure, this machine guarantees structural stability and smooth operation.
3. Efficient Cutting: The Hualong Machinery 2500 Block Cutting Machine can accommodate up to 18 thin saw blades simultaneously, allowing for efficient production of thin slabs.
4. Quality Components: The use of top-quality components such as Hiwin linear guides and Siemens electronic control systems enhances the machine's performance and longevity.
5. Versatile Application: The Hualong Machinery 2500 Block Cutting Machine is suitable for cutting various types of blocks, including granite and marble, making it a versatile choice for different stone cutting needs.
1. Block Cutting: The block stone machine, specifically designed for cutting stone blocks, offers exceptional precision and efficiency in converting blocks into slabs of various thicknesses. Its advanced cutting technology ensures clean and accurate cuts, making it an indispensable tool in the stone processing sector.
2. High-Volume Thin Slab Production: With the capability to mount up to 18 thin saw blades, the block stone machine is ideal for high-volume production of thin stone slabs. This feature is particularly beneficial for construction and design projects that require a large quantity of thin slabs, such as wall cladding, paving, and interior design elements.
3. Stone Fabrication: The block stone machine is widely used in stone fabrication for architectural purposes, including the production of countertops, flooring, and decorative elements. Its precision cutting abilities enable the creation of intricate designs and custom shapes, meeting the diverse needs of architects, designers, and homeowners.
4. Stone Processing Plants: As a key component in stone processing plants, the block stone machine significantly enhances efficiency and quality in the production process. Its ability to cut stone blocks into slabs with speed and accuracy streamlines the workflow, reducing labor costs and ensuring consistent product quality.
5. Domestic and International Markets: The block stone machine has gained popularity in both domestic and international markets due to its high efficiency, stability, and long service life. Stone manufacturers worldwide trust this machine for its exceptional performance, making it a preferred choice for companies seeking reliable and productive stone cutting solutions.
