HSNC-500
Hualong Machinery
Here's the HSNC-500, an automatic bridge type stone edge profiling machine by Hualong Machinery. This advanced stone shaping machine is equipped with the latest technology to provide precise and efficient stone cutting and shaping capabilities. With its Italy CNC system, featuring a user-friendly touch screen interface, setting up and processing stone materials has never been easier. The machine also offers the convenience of mechanical buttons for manual operation of main functions. Powered by the reliable ESA digital servomotor, this machine ensures optimal control and power for the X, Y, and Z axes. The integrated drives and brushless design guarantee seamless integration with Esa's CNCs. Additionally, the laser reticule apparatus, originating from China, assists in aligning the cut at the beginning of the processing, ensuring accuracy and precision. The HSNC-500 is equipped with high-quality electro-spindles controlled by an inverter, allowing for adjustable revolutions ranging from 0 to 6000 rpm. This flexibility enables the use of various tools such as blades and diamond tools for tasks like core drilling or milling cutting. The linear guide, sourced from Hiwin in Taiwan, China, ensures high precision cutting and a long lifespan. In summary, the HSNC-500 automatic bridge type stone edge profiling machine by Hualong Machinery is a top-of-the-line stone shaping machine. With its advanced features, including the Italy CNC system, digital servomotor, laser reticule apparatus, electro-spindles, and linear guide, it offers unparalleled precision and efficiency in stone cutting and shaping. Perfect for granite and marble cutting, this machine is a reliable and indispensable tool for stone professionals.
TECHNICAL DATA FOR HKNC-500 | ||
Diameter of saw blade | ø400-ø500 | mm |
Dimension of working platform | 3300x2000 | mm |
Max. cutting length | 3300 | mm |
Max. cutting thickness | 140 | mm |
Max. lifting stroke | 250 | mm |
Max. lifting weight by sunction cups | 200 | kg |
Power of main motor | 11 | kw |
Power of cutter frame reciproctating motor | 2 | kw |
Power of crossbeam shifting motor | 1.1 | kw |
Power of hydraulic station motor | 2.2 | kw |
Power of lifting motor | 0.85 | kw |
Gross power | 16 | kw |
Water consumption | 2 | m3/h |
Gross weight | 5400 | kg |
Dimensions (L x W x H) | 5700x3260x2765 | mm |
Main Features of the Automatic Bridge Type Stone Edge Profiling Machine (HSNC-500) by Hualong Machinery:
1. Controlled by Siemens PLC system for expedient, accurate, and stable operation.
2. One-button automatic vertical and horizontal cutting for enhanced efficiency.
3. Cutting head can rotate 0°-360° and position automatically. Blade can tilt 0-90° and perform chamfering automatically.
4. Equipped with drilling and milling functions, making round sink processing easier and faster.
5. Working platform can rotate 0-360°, allowing positioning at any angle, and tilt 85° for easy feeding.
6. Mono-block machine design facilitates container loading and machine installation.
1. Precision Control: The HSNC-500, an automatic bridge type stone edge profiling machine by Hualong Machinery, is controlled by the Siemens PLC system, ensuring expedient, accurate, and stable operation. This guarantees precise stone cutting, making it ideal for stone shaping machines.
2. Efficient Operation: With one-button automatic vertical and horizontal cutting, the HSNC-500 streamlines the cutting process for maximum efficiency. This feature saves time and effort, making it a valuable tool for stone cutting machine granite, marble cutting machine cutter, stone saw cutting machine, and Stone Cutting Concrete.
3. Versatile Cutting Options: The HSNC-500 offers versatile cutting options with its cutting head that can rotate 0°-360° and automatically position itself. Additionally, the blade can tilt 0-90° for chamfering. This flexibility allows for various cutting styles and techniques, meeting the needs of different stone shaping requirements.
4. Additional Functions: Equipped with drilling and milling functions, the HSNC-500 enhances productivity by making tasks like round sink processing faster and easier. This feature adds value to the machine, providing more functionality and versatility for stone shaping projects.
5. Flexible Work Platform: The HSNC-500's working platform can rotate 0-360° and tilt up to 85°, allowing for easy feeding from various angles. This flexibility ensures convenience and efficiency during operation, making it a reliable choice for stone shaping machines.
6. Compact Design: Being a mono-block machine, the HSNC-500 is easy to load into containers and install. This compact design offers convenience and cost-effectiveness, making it a practical choice for stone shaping projects.
In summary, the HSNC-500 automatic bridge type stone edge profiling machine by Hualong Machinery offers precision control, efficient operation, versatile cutting options, additional functions, a flexible work platform, and a compact design. These advantages make it a valuable tool for stone shaping machines, catering to the needs of the stone machinery industry.
Product Application: Automatic Bridge Type Stone Edge Profiling Machine
1. Stone Shaping: The HSNC-500, manufactured by Hualong Machinery, is an automatic bridge type stone edge profiling machine designed specifically for shaping stone surfaces. Its precision cutting and versatile angle adjustments ensure that stone countertops and slabs are crafted with perfection.
2. Stone Countertops: The HSNC-500 is especially suitable for processing stone countertops, including those with sinks. Its high-precision cutting capabilities and versatile rotation allow for precise shaping and profiling of stone surfaces, resulting in beautifully finished countertops.
3. Stone Slab Cutting: This machine is ideal for cutting various types of stone slabs, such as granite, marble, quartzite, and artificial stone slabs, to the desired sizes. With its advanced control systems and top-quality linear guides, it ensures high-precision cutting for flawless results.
4. Relief Processing: The HSNC-500's capabilities extend to relief processing, allowing for intricate designs and patterns to be carved into stone surfaces. Its drilling and milling functions enable the creation of holes and fine detailing, enhancing the aesthetic appeal of stone artworks and architectural elements.
5. Versatile Applications: With its ability to rotate the work platform at any angle (0-360°), the HSNC-500 adapts to different cutting and processing requirements. Whether it's stone shaping, countertop fabrication, relief processing, or intricate detailing, this machine offers versatility and precision for a wide range of stone applications.
6. Industry-leading Technology: Hualong Machinery's HSNC-500 incorporates top-quality linear guides and advanced control systems, ensuring high-precision cutting tasks. Its state-of-the-art features make it a reliable and efficient choice for stone processing professionals in the stone machinery industry.
